Highlights
*3200mm wheel base makes machine both stable and flexible, central articulation
with small turning radius that makes machine could work in narrow jobsite.
*Three-stage air filters is utilized specially for heavy-dusty working environment
which could avoid early wear out of engine to prolong service time.
*Multi-stage fuel filter is suitable for variable fuel which could improve the clearance of the engine system.
*LOVOL Patented gearbox adopts reinforced overrunning clutch which could
provide longer service time to the whole transmission system.
*High-efficiency powertrain system is perfectly matched with hydraulic multi-stage
power system that makes machine work fast and efficient to save energy.
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
162 |
Operating Weight |
kg |
16950 |
Bucket Capacity |
m³ |
3 |
Engine Model |
- |
WEICHAI WD10G220E23 |
Max. Breakout Force |
kN |
160 |
Rated Load |
kg |
5000 |
Max. Traction Force |
KN |
160 |
Max. Gradeability |
° |
30 |
Max. Dump Clearance |
mm |
3140 |
Dump Reach |
mm |
1090 |
Wheel Tread |
mm |
2150 |
Wheelbase |
mm |
3200 |
Overall Dimension(L×W×H) |
mm |
8060×2980×3380 |
Type |
- |
Double pump flow conffluence, flow amplifying hydraulic system |
Steering Angle Each Direction |
- |
37º |
Min. Turning Radius |
mm |
6930 |
Working Pressure |
Mpa |
18 |
Boom Lifting Time |
s |
5.7 |
Total Cycle Time |
s |
10.6 |
Fuel Tank |
L |
280 |
Hydraulic Tank |
L |
140 |
Engine Oil |
L |
20L |
