Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
92 |
Operating Weight |
kg |
10300 |
Bucket Capacity |
m³ |
1.8 |
Engine Model |
- |
WP6G125E22 |
Max. Torque |
N.m |
500 |
Rated Load |
kd |
3000 |
Max. Traction Force |
KN |
97 |
Max. Gradeability |
° |
27 |
Max. Dump Clearance |
mm |
2905 |
Dump Reach |
mm |
1095 |
Wheel Tread |
mm |
1850 |
Wheelbase |
mm |
2850 |
Overall Dimension(L×W×H) |
mm |
7200x2500x3180 |
Type |
- |
Hydraulic load sensing system |
Steering Angle Each Direction |
- |
35º |
Min. Turning Radius |
mm |
6190 |
Working Pressure |
Mpa |
16 |
Boom Lifting Time |
s |
- |
Total Cycle Time |
s |
9 |
Fuel Tank |
L |
200 |
Hydraulic Tank |
L |
150/155(3rd spool) |
Engine Oil |
L |
14 |
