Highlights
*Heavy-duty machine, the Key components have passed harsh test and examination to be proved reliability and durability.
*HANGCHI YD130 power shift transmission makes operation more convenient and comfortable with soft impact during gear switching.
*LOVOL patented composite articulation structure makes the central-hinge more stable and robust.
*The proven linkage structure is very efficient which has big breakout force, quick movement and high lifting capacity features.
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
105 |
Operating Weight |
kg |
10770 |
Bucket Capacity |
m³ |
2 |
Engine Model |
- |
WEICHAI WP6G140E22 |
Max. Breakout Force |
kN |
115 |
Rated Load |
kd |
3500 |
Max. Traction Force |
KN |
105 |
Max. Gradeability |
° |
30 |
Max. Dump Clearance |
mm |
2930 |
Dump Reach |
mm |
1100 |
Wheel Tread |
mm |
1850 |
Wheelbase |
mm |
2880 |
Overall Dimension(L×W×H) |
mm |
7170*2425*3200 |
Type |
- |
Double pump flow conffluence, load-sensing hydraulic system |
Steering Angle Each Direction |
- |
38º |
Min. Turning Radius |
mm |
5990 |
Working Pressure |
Mpa |
17.5 |
Boom Lifting Time |
s |
5.5 |
Total Cycle Time |
s |
9.4 |
Fuel Tank |
L |
150 |
Hydraulic Tank |
L |
110 |
Engine Oil |
L |
14.5L |
