Highlights
*The extended wheelbase makes the vehicle more stable and copy with various
complex conditions easily.
*The cab offering a panoramic view and wide vision allows operator to observe
surroundings during operation.
*Multi-stage fuel filter could suitable for various fuel to ensure the cleanliness of
engine system, that raise engine’s reliability.
*Central articulation providing the small turning radius which could makes machine
work in the narrow job site.
Parameters
Item |
Unit |
Parameter |
Rated Power |
kW |
92 |
Operating Weight |
kg |
10300 |
Bucket Capacity |
m³ |
2 |
Engine Model |
- |
WEICHAI WP6G125E22 |
Max. Breakout Force |
kN |
98 |
Rated Load |
kd |
3000 |
Max. Traction Force |
KN |
101 |
Max. Gradeability |
° |
30 |
Max. Dump Clearance |
mm |
2930 |
Dump Reach |
mm |
1100 |
Wheel Tread |
mm |
1850 |
Wheelbase |
mm |
2880 |
Overall Dimension(L×W×H) |
mm |
7230*2425*3200 |
Type |
- |
Single pump flow diffluence, load - sensing hydraulic system |
Steering Angle Each Direction |
- |
38º |
Min. Turning Radius |
mm |
6020 |
Working Pressure |
Mpa |
16 |
Boom Lifting Time |
s |
5.6 |
Total Cycle Time |
s |
9.2 |
Fuel Tank |
L |
150 |
Hydraulic Tank |
L |
105 |
Engine Oil |
L |
14.5L |
