Products Highlights
*Standard equipped with YANMAR engine with high power, environmentally friendly and clean.
*The tailless design and excellent side movement capacity of boom enables you to
operate in the narrow space flexibly.
*Three-pump full-power automatic regulation system adjusts working power as
required, and is always efficient and energy-saving.
*Flexibility characteristics such as telescopic chassis, folding dozer blade and
build-in working pipelines help you complete work efficiently.
Products Parameters
|
Item
|
Unit
|
Parameter
|
|
Rated Power
|
kW/rpm
|
11.5/2400
|
|
Bucket Capacity
|
m³
|
0.04
|
|
Operating Weight
|
kg
|
1810
|
|
Engine Model
|
-
|
YANMAR 3TNV70-PFN
|
|
Number of Cylinders
|
-
|
3
|
|
Max. Torque/Speed
|
N.m/rpm
|
48/1600
|
|
Displacement
|
L
|
0.854
|
|
Bucket Digging Force
|
kN
|
15.2
|
|
Arm Digging Force
|
kN
|
8.5
|
|
Max. Traction Force
|
kN
|
13.5
|
|
Max. Walking Speed
|
km/h
|
3.7
|
|
Min. Walking Speed
|
km/h
|
1.9
|
|
Rotary Speed
|
r/min
|
9
|
|
Gradeability
|
。
|
30°
|
|
Ground Pressure
|
KPa
|
29
|
|
Max. Main Pump Flow
|
L/min
|
2X17.2＋10.8
|
|
Main Safety Valve Pressure
|
MPa
|
21.6
|
|
Fuel Tank
|
L
|
19
|
|
Hydraulic Tank
|
L
|
13
|
|
Engine Oil
|
L
|
1.3-2.8
|
